60W, 12V LED Power Supply w/o Wiring Chambers

ANP90-12P

 Purchasing Information

Description

ANP90 Series is Amperor's 90W, universal input, rugged, Class II switching mode LED power supply. The combination of the potting compound in which its LED driver circuitry is encapsulated and water-tight connectors on the input and output wiring chambers, makes the ANP90 suitable for use in wet locations. Its tough extruded aluminum case ensures the ANP90 will handle all of your rugged outdoor or indoor lighting needs. Thus, sign illumination, backlighting, architectural, step and border lighting, will display, regardless of weather conditions.

The single channel, +12V output ANP90-12P has the industry's best thermal performance, guaranteed to output at full load between -30~70 degrees C. The characteristic of non-de-rated output power up to 70 degrees C makes it cost efficient for LED system developers. Multiple power supplies are not required in order to maintain the same level of LED output in a high temperature location. Furthermore, the ANP90-12P has a built-in, active power factor correction (PFC) capability. Along with an 85% + efficiency level, it is proven to be an environment friendly solution.

ANP90-12PY is a similar version with the wiring chambers installed. Please click here to check out the ANP90-12PY.

Features

• Universal AC Input
• High Efficiency Rating
• Fantastic Thermal Performance
• Class II
• Built for Outdoor / Indoor, Wet / Dry location
• Active Power Factor Correction (PFC) Capability
• Built-in Protection Circuitry
• Long MTBF
• RoHS complient
• UL1310, IP65, UL879 (SAM), EN60950-1, TUV, CE, FCC Certified

Specifications

• Dimensions (w/o wiring chambers): 200mm (l) x 60mm (w) x 43mm (h)
• Input voltage : 90 to 264VAC, 47 to 63 Hz
• Efficiency: > 85% (Typical)
• Output: +12V @ 5A
• # of output channels: 1
• Output mode: C.V. and C.C. mode, see datasheet for details.
• Max. output power: 60W
• Operating ambient : -30°c to 70°c
• MTBF: 100,000 hours @ 25°c
• For mechanical drawing and other specifications, click here to see the detailed datasheet.

Inquiry for Bulk Buying or Custom Requests

ANP90 series LED power supply can be configured to output different voltages. Please EMAIL AmperorDirect Support Team or call 281-664-1209 for details.
